Product Details:
|
| Product Model: | NYRD-SL | Measurement Accuracy: | 0.05%~0.1% F.S |
|---|---|---|---|
| Antenna Material: | PTFE, 304/316, PP, PFA | Measuring Range: | 10m, 20m, 30m, 35m, 40m |
| Power Supply: | 24VDC(two Wire, Four Wire), 220VAC | Signal Output: | 4... 20mA/HART/RS485/Modbus |
| Process Pressure: | - 0.1 ~ 0. 3MPa, - 0. 1 ~ 2. 0MPa, - 0. 1 ~ 4. 0MPa | Process Temperature: | - 40 ~ + 130 ℃, -40 ~ + 150 ℃, -40 ~ + 260 ℃ |
| High Light: | Smart Acid Water Tank Level Meter,Water Tank Radar Level Meter,PTFE Antenna Liquid Level Meter |
||
Smart Acid Water Tank Radar Liquid Water Level Meter intelligent
Smart Acid Water Tank Radar Liquid Water Level Meter intelligent Description
The radar level meter NYRD80X series sensor is a 26GHz high-frequency radar level measuring instrument with a maximum measurement distance of 80 meters. The antenna is further optimized, and the new fast microprocessor can perform higher-speed signal analysis and processing, so that the instrument can be used for some complex measurement conditions such as reaction gold and solid silos.
Smart Acid Water Tank Radar Liquid Water Level Meter intelligent Working Principle
The radar level antenna emits narrow microwave pulses, which are transmitted downward through the antenna. After the pulse wave touches the surface of the measured medium, it is reflected back and received by the antenna system again, and the signal is transmitted to the electronic circuit part and automatically converted into a level signal (because the pulse propagation speed is extremely fast, the electromagnetic wave reaches the target and is reflected back to the receiver. The time it takes to go back and forth is almost instantaneous)
Smart Acid Water Tank Radar Liquid Water Level Meter intelligent Design Feature
◎Antenna size is small, easy to install, non-contact radar, no wear, no pollution.
◎Almost impervious to corrosion and foam. Not affected by medium density, temperature and pressure change.
◎Serious dust environment has little effect on the work of high frequency level meter.
◎Shorter wavelengths, better reflection of sloping solid surfaces.
◎Beam Angle is small, energy concentration, enhance the echo ability at the same time is conducive to avoid interference.
◎The measurement blind area is smaller, and good results can be achieved for small tank measurement.
◎High signal-to-noise ratio, even in the case of fluctuations can achieve better performance.
◎High frequency, is the best choice for measuring solid and low dielectric constant media.
