High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability

High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability
High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability

Large Image :  High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability

Product Details:
Place of Origin: Xi'an,Shannxi,China
Brand Name: NUOYINGJIAYE
Certification: CE,ATEX,SIL
Model Number: NYRD805
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: $620~$860/pcs
Packaging Details: Carton, 30cm x 20cm x 20cm
Delivery Time: 7 working days
Payment Terms: T/T
Supply Ability: 1000 pcs/per month

High Frequency NYRD805 Radar Level Transmitter PTFE Echo Ability

Description
Application: Various Corrosion Liquid Antenna Material: PTFE
Measurement Range: ≤10m Medium Temperature: -40℃~+130℃
Process Pressure: -0.1〜0.3MPa Explosion-proof Grade: Exd II CT6 Gb
Signal Output: 4... 20mA/HART Accuracy: ±3mm
High Light:

Echo Radar Level Transmitter

,

PTFE Radar Tank Level Indicator

,

Radar Liquid Level Transmitter High Frequency

High Frequency NYRD805 Radar Level Transmitter PTFE Better Performance Echo Ability





High Frequency NYRD805 Radar Level Transmitter



The NYRD805 radar level meter is a 26GHz high-frequency radar level measuring instrument with a maximum measurement distance of 10 meters. The antenna is further optimized, The beam angle is small and the energy is concentrated, which enhances the echo ability and helps to avoid interference.and the new fast microprocessor can perform higher-speed signal analysis and processing, so that the instrument can be used in some complex occasions such as steam, foam, dust, crystallization, condensation, etc..The measurement blind area is smaller, and it can also achieve good results for small tank measurement.



High Frequency NYRD805 Radar Level Transmitter Technical Parameter



Application various corrosion liquid
Antenna material PTFE
Measurement range ≤10m
Frequency range 26GHz
Accuracy ±3mm
Medium temperature -40℃~+130℃
Process pressure -0.1〜0.3MPa
Power supply 24VDC (two lines, four lines),220VAC
Process connection Thread, Flange,Hygiene collar
Protection grade IP67
Explosion-proof grade Exd II CT6 Gb
Signal output 4... 20mA/HART



Note: Products can be customized according to the specific requirements of users!
