Compact Structure Industrial Radar Level Meter Non Contact 80ghz

Name: Compact Structure Industrial Radar Level Meter Non Contact 80ghz
Brand: Shaanxi Nuoying Automation Instrument Co., Ltd.
SKU: NYRD805
Price: 625.00 USD
Availability: InStock

Brand Name:	NUOYINGJIAYE
Model Number:	NYRD805
MOQ:	1pcs
Price:	400-850
Payment Terms:	T/T
Supply Ability:	660 pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

Xi'an, Shaanxi,China

Certification:

Typical Application:

Various Liquids,dust,solids

Product Model:

NYRD805

Antenna Type:

Anti Corrosion Antenna(PTFE)

Antenna Material:

304, PTFE

Measuring Range:

10m, 20m, 30m

Process Temperature:

-40°C~+260°C( Above 260 °C Customized)

Process Pressure:

-0.1~2.0Mpa

Measurement Accuracy:

0.05%~0.1% F.S

Packaging Details:

Carton, 60cm×30cm×30cm (default)

Supply Ability:

660 pcs per month

Highlight:

26ghz Non Contact Radar Level Transmitter

Anti Corrosion Antenna Radar Level Meter

Industrial Compact Radar Level Transmitter 10m

Product Description

Rs485 modbus radar type water level sensor transmitter

NYRD-901 Radar Water Level Meter

The NYRD901 Frequency Modulation wave FMCW radar product (also known as millimeter wave radar) has important applications in remote target detection, remote imaging, multispectral imaging, etc. In the environment of strong smoke and dust, because it uses a millimeter wave band with a higher frequency than the Ku band radar. It can detect targets smaller than the microwave radar and achieve more accurate positioning, with higher resolution and stronger confidentiality.

NYRD-901 Radar Water Level Meter Technical Parameters

Typical application	water, liquids
Measuring range	5m, 10m, 15m, 20m
Power Supply	24VDC(22V~30V)
Signal output	4...20mA/RS485/Modbus..
Ambient temperature	-20℃~+70℃
Process pressure	-0.1~1.0Mpa
Connection method	Thread
Protection Grade	IP67

Notes: The products can be customized according to customers requirement!

NYRD-901 Radar Water Level Meter Certificate

Compact Structure Industrial Radar Level Meter Non Contact 80ghz 0

NYRD-901 Radar Water Level Meter Working Condition

Compact Structure Industrial Radar Level Meter Non Contact 80ghz 1
