304 PTFE Flat Probe RF Admittance Level Switch For Bulk Material

304 PTFE Flat Probe RF Admittance Level Switch For Bulk Material
304 PTFE Flat Probe RF Admittance Level Switch For Bulk Material

Large Image :  304 PTFE Flat Probe RF Admittance Level Switch For Bulk Material

Product Details:
Place of Origin: Xi'an, Shaanxi,China
Brand Name: NUOYINGJIAYE
Certification: CE
Model Number: NYSP-UK863
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: $200~$300/pc
Packaging Details: Carton, 60cm×30cm×30cm
Delivery Time: 7 working days
Payment Terms: T/T
Supply Ability: 1000 pcs/month

304 PTFE Flat Probe RF Admittance Level Switch For Bulk Material

Description
Typical Application: Bulk Material Product Models: NYSP-UK865
Power Supply: 24VDC Or 220VAC Probe Rod Material: 304+PTFE
Probe Rod Length: 500mm Process Temperature: -184℃~+260 ℃
Time Delay: 0 To 30s Adjustable Power Loss Protection: Normally Open Or Normally Closed
High Light:

Flat Probe RF Admittance Level Switch

,

Bulk Material RF Admittance Level Switch

,

304 PTFE RF Admittance Level Transmitter

Flat Probe RF Admittance Level Switch For Bulk Material



Working Principle of Flat Probe RF Admittance Level Switch For Bulk Material



Radio frequency admittance level switch, its measurement principle is: radio frequency admittance is a new type of level control technology developed from capacitive, anti-hanging, more reliable, more accurate and more applicable. Level technology upgrade. The so-called radio frequency admittance means the inverse of the impedance in electricity. It is composed of resistive components, capacitive components, and inductive components, and radio frequency is the high-frequency radio spectrum. Therefore, radio frequency admittance can be understood as the use of high frequency. Radio waves measure admittance. When the meter is working, the sensor of the meter forms an admittance value with the filling wall and the measured medium. When the material level changes, the admittance value changes accordingly, and the circuit unit converts the measured admittance value into a level signal output to realize the level measurement.


Design feature of Flat Probe RF Admittance Level Switch For Bulk Material



◎this product uses intelligent microprocessor components and difference measurement technology, which can measure water, sewage, mud and other liquids, especially can effectively and accurately measure strong corrosive media, and can dynamically compensate for environmental changes and hanging materials;

◎the operation is very simple. You only need to adjust the corresponding sensitivity knob according to the medium and use the surge delay filter;

◎ the upper and lower limit alarm modes can be flexibly set, and the user can set and select the normally open and normally closed contacts by himself;

◎High performance imported single pole double throw relays are used for single point and multi-point relays. The single point contact current capacity can reach 8A and the multi-point relay 3A. Can directly drive alarm devices within the range;

◎ PTFE probe is used. There is no movable device at the detection position. It is impact resistant, high-temperature resistant and corrosion-resistant.



Technical parameters of Flat Probe RF Admittance Level Switch For Bulk Material



Typical application High and low alarm for liquid, dust, particles, solids and other media
product model NYSP-UK861,NYSP-UK862,NYSP-UK863,NYSP-UK864,NYSP-UK865,NYSP-UK866
Probe rod form Cable type, pole type and flat type
Probe rod material 500mm(The length can be customized according to the site conditions)
Power Supply 24VDC,220VAC
Signal Output Double pole double throw relay (DPDT) output, 5A 24VDC or 5A 220VAC
Ambient Temperature -40~+80℃
Process Temperature -40~+130℃,-184~+260℃,>260℃Select ceramic high temperature probe
Process pressure -0.1~2.0MPa
Process connection screw thread,brackets,flange(selectable)
time delay 0-30s adjustable
Power loss protection Normally open, normally closed, field switchable
sensitivity 0.5pf~750pf
Fault alarm Upper or lower limit, adjustable on site
levels of protection IP67
Explosion-proof grade Exia II CT6 Ga,Exd II CT6 Gb(See certificate for details)



※Note:The product can be customized according to the specific requirements of users.
