Strong Corrosive Liquid Non Contact 26GHz NYRD-TJ Radar Water Level Sensor Measurement Transmitter
NYRD-TJ-A Radar Level Transmitter Overview
Products Description
26GHz NYRD-PB Radar Level Transmitter Working Principle
Radar level meter NYRD80X series sensor is a 26GHz high-frequency radar level measuring instrument with a maximum measuring distance of 80m. The radar object position antenna emits a narrow microwave pulse that is transmitted downward through the antenna. After the pulse wave touches the surface of the measured medium, it is reflected back and received by the antenna system again. The signal is transmitted to the electronic circuit part and automatically converted into object level signal (Because pulses travel so fast, the time it takes for an electromagnetic wave to reach its target and bounce back to the receiver is almost instantaneous).
The datum of measurement: Spiral bottom surface or sealing surface of flange.
Product Parameters
Typical application
Easy to crystallize, dew condensation, toxic, strong corrosion
Antenna
material
Lens Antenna, 316L+PTFE (Optional)
Measuring range
40m
Measuring accuracy
0.05%-0.1%F.S
Power supply
24VDC(Two lines, four
lines)
Medium temperature
-40~+120℃,-40~+260℃
Process connection
Flange,bracket (optional)
Process pressure
-0.1~2.0MPa
Dimensions of the shell structure of the radar level meter (unit: mm)
There are two types of radar level meter:
One is the cast aluminum shell and the other is a stainless steel case.Customized design can be made according
to customer requirement and site condition.
