NYCL - 100B Water Portable Ultrasonic Flowmeter Cold Heat Measurement

NYCL - 100B Water Portable Ultrasonic Flowmeter Cold Heat Measurement
NYCL - 100B Water Portable Ultrasonic Flowmeter Cold Heat Measurement

Large Image :  NYCL - 100B Water Portable Ultrasonic Flowmeter Cold Heat Measurement

Product Details:
Place of Origin: Xi'an, Shaanxi,China
Brand Name: NUOYINGJIAYE
Certification: CE
Model Number: NYCL-100B
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: $450 to $1700 /pcs
Packaging Details: Carton, 60cm×30cm×30cm
Delivery Time: 7 working days
Payment Terms: T/T
Supply Ability: 1000 pcs/ pre month

NYCL - 100B Water Portable Ultrasonic Flowmeter Cold Heat Measurement

Description
Measuring Principle: Ultrasonic Time Difference Type Principle Measuring Range: 0~±10m/s
Power Supply Method: Built-in NiMH Rechargeable Battery, Can Continue To Work 15-20 Hours Measurement Media: Water, Seawater, Sewage, Alcohol, Various Oils And Other Media That Can Conduct Ultrasound In A Single, Uniform, Stable Liquid
Media Turbidity: ≤20,000ppm And Small Bubble Content Applicable Tubes: Carbon Steel, Stainless Steel, Cast Iron, Copper, PVC, Aluminum, Glass Fiber Reinforced Plastic And Other Uniform Quality And Density Of The Pipe, Allowing A Lining Straight
High Light:

Cold Heat Measurement Portable Ultrasonic Flowmeter

,

Water Portable Ultrasonic Flowmeter

,

Stainless Steel Ultrasonic Water Flowmeter

Realize The Function Of Cold And Heat Measurement NYCL-100B Type Portable Ultrasonic Flowmeter





NYCL-100B Type Portable Ultrasonic Flowmeter Working Principle



NYCL-100B portable ultrasonic flowmeter/calorimeter is suitable for online calibration and inspection measurement of liquid flow and heat in various industrial sites, mostly used for temporary detection and printing of on-site data; it can also be equipped with SD card for data storage, which is convenient for uploading data, statistics and analysis in the future; it can also realize the function of cold and heat measurement by adding temperature sensor (external paste type is optional), and can conduct real-time detection of cold and heat.



NYCL-100B Type Portable Ultrasonic Flowmeter Technical Parameters



Measuring principle Ultrasonic time difference type principle
Measuring range 0~±10m/s
Measuring accuracy ±1.0%
Direction of flow Positive and negative bi-directional metering, and measurement of positive, negative and net cumulative flow heat
Data Interface RS485 serial interface, can be upgraded through the PC computer to the flowmeter, support Modbus and other protocols
Data logging External SD card data memory, can store time, instantaneous flow, cumulative flow, etc., and can import data to computer
Signal output 4-20mA output, OCT pulse output, relay output.
Power supply method Built-in NiMH rechargeable battery, can continue to work 15-20 hours
Measurement media Water, seawater, sewage, alcohol, various oils and other media that can conduct ultrasound in a single, uniform, stable liquid
Media turbidity ≤20,000ppm and small bubble content
Applicable Tubes Carbon steel, stainless steel, cast iron, copper, PVC, aluminum, glass fiber reinforced plastic and other uniform quality and density of the pipe, allowing a lining straight
Pipe Section The sensor installation point should preferably meet: 10D upstream, 5D downstream, 30D from the pump outlet
